Fully Automatic Vertical Plug Pull Force Testing Machine Automatic Plug Life Cycle Durability Testing Machine

Ask Lasest Price
Brand Name :	HUAKAI
Price :	$1,000-3,000 / piece

Add to Cart

Product Details
Company Profile

Fully Automatic Vertical Plug Pull Force Testing Machine Automatic Plug Life Cycle Durability Testing Machine

Product Overview

Automatic connector insertion and extraction force testing machine is designed for accurate testing of connector insertion force, pull-out force and durability performance. The equipment is widely used in electronic connector manufacturing, R&D laboratories and quality inspection departments.
Equipped with automatic centering device and precision motion control system, the tester ensures perfect alignment of male and female connectors, eliminating uneven force issues and providing highly reliable testing results. The system supports full data acquisition, curve analysis and report generation.
Functions & Applications
* Connector insertion and extraction force testing
* Connector durability and life cycle testing
* Single pin retention force testing
* Connector normal force testing
* Force vs displacement curve analysis
* Compression and tensile testing
* Electronic connector R&D verification
* Quality control in connector manufacturing

Product Paramenters

Item	Specification
Maximum load	50kg
Minimum load resolution	0.01gf
Units	N / gf / kgf / lbf
Test speed	0–300mm/min
Maximum stroke	0–150mm
X-Y axis travel	0–75mm
Transmission system	Ball screw
Minimum adjustment	0.01mm
Drive motor	High precision motor
Machine size	360×260×940mm
Weight	76kg

Products Description

Structure & System Configuration
* Automatic centering alignment system
* High precision ball screw transmission
* X-Y movable testing platform
* High sensitivity load sensor system
* Computer controlled testing system
* Windows based operation interface
* Real-time force and displacement monitoring
* Multi-functional connector testing fixtures
Software & Testing Functions
* Insertion and extraction force curve analysis
* Connector life cycle curve generation
* Force vs displacement data recording
* Unlimited data storage capability
* Customizable test parameters
* Report export in Word, Excel and PDF formats
* Bilingual report editing (Chinese & English)
* Automated report generation and printing
Safety & Protection
* Overload protection system
* Emergency stop function
* Upper and lower travel limit protection
* Software limit protection setting
Standard Configuration
* Main testing machine ×1
* Industrial computer with display ×1
* Load sensor (AL-20K) ×1
* High precision motor system ×1
* Ball screw transmission system ×1
* Control software package ×1
* X-Y movable platform ×1
* Multi-purpose fixtures ×1 set
* Multi clamps ×3 sets
* Single pin retention fixture ×1
* Pin extraction fixture ×1
* RS-232 data cables ×2
* Power cable ×1
* Tools and documents ×1 set

Details Images

Certifications

Company Profile

Product packaging

Packaging & Shipping

• Internal Protection: Anti-collision foam padding and moisture-proof wrapping are applied to prevent mechanical damage and corrosion during transit. • Marking & Labeling: Each package is clearly labeled with model number, dimensions, weight, and handling instructions for easy identification. • Loading: All packages are reinforced and suitable for forklift handling and container loading.

• Shipping Options: By sea, air, or express courier according to customer preference.
